The information below is mainly for my reference.
Changes made per test to the base slicing profile
#Mass effect font slicer download#
The information above is a summary, but if you wish to see the exact settings, the Simplif圓D fff profile is available for download here. The default end gcode is as follows (this can be completely replaced by ticking the approprpriate option on each form): G28 X0 home X axis G0 Z3 fix for delta printers that home at max`
This calibration test gcode modified by the Teaching Tech Calibration website: The default start gcode is as follows (this can be completely replaced by ticking the approprpriate option on each form): G-Code originally generated by Simplif圓D(R) Version 4.1.2
No minimum layer time, auto part cooling, etc.A single layer skirt (except on the acceleration test).Use the custom start gcode feature to insert the priming sequence from your slicer profile. Nozzle priming has been turned off to avoid bed clips or problems with delta printers.Please see the note on the bottom of the flow tab for instructions on adapting this to your printer. Modifiers include 60% for perimeters, 80% for solid infill, 166% travel moves, and 50% for the first layer Line width on auto, typically 120% of nozzle diameter.0.4mm nozzle and 0.2mm layer height, although now additional configurations are now possible.Absolute extrusion values (M82 as opposed to relative/M83).1.75mm filament (However M221 S38 for 2.85 mm filament and M221 S34 for 3.0 mm filament can be applied in the custom start gcode field as compensation).A build volume of 120 x 120 x 250 mm (This site can accommodate anything as small as this and anything larger).Sliced for Marlin firmware, although in most cases will still be compatible with other firmwares.The general characteristics of the slicer profile are as follows: Apart from this, the only special functionality used is post processing scripts to delete some lines, and to modify others with simple search and replace functions. S3D offers multiple processes to assist with splitting the towers into segments where the print settings can vary. Print Settings from the calibration S3D slicer profileĪ 'calibration' slicer profile in S3D is used as the basis of the gcode on this site. Something that makes the experience better for 1% of users but confuses 40% of others is not worth including. Because of this, some requests for extra functionality will not be accepted. It aims to be beginner friendly and as such where possible the interface is kept as minimal as possible. The aim for the site is to provide compatibility with the majority of 3D printers. This site is not a web based slicer, therefore it is limited in some ways. This website then uses Javascript to modify the contents based on user inputs. The gcode generated by this page is originally from Simplif圓D. Validation has been built into the forms to only allow sensible min and max values, however this is not foolproof. Only print this gcode when you are present, alert and capable of stopping the printer in case of emergency. Preview the gcode in your slicer or Zupfe GCode Viewer and print at your own risk. Every attempt has been made to ensure this is safe but ultimately there always is risk in running pre-sliced gcode from the internet.
